Single product

This 4-channel NVR features H.265+/H.264 dual codec decoding and supports up to 8MP resolution preview and playback with a maximum incoming bandwidth of 80Mbps. It supports 1 SATA HDD (up to 6TB) and includes 2 USB 2.0 ports for flexible data management. The system offers HDMI and VGA simultaneous video output and is compatible with multi-brand network cameras with ONVIF 2.4 conformance. Powered by a dual-core embedded processor running on Embedded LINUX, the NVR supports up to 4 IP camera inputs and a GUI-based user interface. Video outputs include 1 HDMI and 1 VGA, with resolutions supported up to 1920?1080, 1280?1024, and 1280?720. It records up to 40Mbps at various resolutions including 6MP, 5MP, 4MP, 3MP, 1080P, 720P, and D1. Display options include 1/4 split screens. Motion detection supports 396 zones (22?18), and camera blanking and video loss detection are also supported. One SATA III port supports up to 4TB hard disk capacity. Mobile access is available via iPhone, iPad, and Android phones. Trigger events include recording, PTZ, tours, video push, snapshot, and screen tips. Recording modes include manual, schedule (regular/continuous), motion detection, and stop. Playback options are extensive and include play, pause, stop, rewind, fast and slow play, file navigation, full screen, repeat, shuffle, and backup selection with digital zoom. Backups can be performed via USB device or network. Recording intervals range from 1?120 minutes (default: 60 min) with pre-recording of 1?30 seconds and post-recording of 10?300 seconds. It supports a maximum of 128 user accounts. Network connectivity includes a single RJ-45 port (10/100Mbps) and protocols such as HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, IP Search, ONVIF, SDK, and CGI. Power is supplied via a single DC12V/1.5A input with a power consumption of less than 2.57W (without HDD). The device operates in temperatures from -10?C to +45?C, humidity levels from 0?90%RH, and air pressure of 86?106kPa. Dimensions are 197mm ? 196.6mm ? 41.5mm, and it weighs 1.15kg without the HDD. Includes a two-year warranty.
